NEW FEATURES: APOLLO & APOLLO OPTION (ODYSSEY7Q+/7Q)
Dual-4K/Quad-HD: Multi-Stream Audio Meters
- Dual-4K: Audio meters are displayed for the first four channels of each input
- Quad-HD: Audio meters are displayed for the first two channels of each input
- Expanded controls & descriptions in Audio menu
Dual-4K: PiP Left/Right Selection
- Dual-4K Picture-in-Picture display can be lower-left or lower-right
- Select in DUAL menu
Dual-4K: 4K60p Apple ProRes Support (Apollo)
- Record single channel of 4K60p in Apollo
- NOTE: Function already available in Odyssey7Q+/7Q Apollo Mode
Quad-HD: Double Master Recording
- Simultaneously record identical files to both SSDs
- 1080p 23.98, 24, 25, 29.97, 30
- 1080i 50, 59.94; 720p 50, 59.94, 60
Quad-HD: A/V Align
- Individually adjust frame delay to audio and/or video of each input
- Add up to four frames delay per video track
- Add up to seven frames delay per audio track
- Note: Not available when using 3:2 Pulldown Removal
Quad-HD: 3:2 Pulldown Removal Support
- 24p signals embedded within 1080i60 streams recorded as 1080p24
- Intermix 3:2 Pulldown signals (24p within 60i) with 24p/24psf signals
- Note: Not available when using A/V Align
Quad-HD: Markers During Record
- Set Markers while in Record
- During Record, MARKER button replaces Safe-Eject button
Quad-HD: Improved Focus Assist Access
- Option to switch HIDE button to FOCUS (Focus Assist) for easier access
Quad-HD Live-Switch: Dissolves
- Added dissolves (slow/medium/fast) in Live-Switch recording & output
- CUT/FADE shortcut button replaces * button during recording
- Dissolve speeds: Slow = 16 frames, Medium = 8 frames, Fast = 4 frames
- Select dissolve speed in QUAD menu
Quad HD Live-Switch: Audio-Follows-Video
- Live-Switch option to also switch audio source along with video source
- Affects audio source to Live-Switch recording and output
- Select in Audio menu
- Audio fade-out/fade-in transition is 21 milliseconds to smooth audio cuts
Quad-HD Live-Switch: OLED Monitor-Only Switching
- Switch OLED view without affecting Live-Switch recording or output
- Select OLED view using Lower Toolbar QUAD/A/B/C/D buttons
- NOTE: Monitor-Only Switching affects SDI A & SDI B outputs unless they are set to Preview (SDI A Out) & Program (SDI B Out)
Quad-HD Live-Switch: Single-Tap/Double-Tap Switching
- Switch inputs with a single tap or use double-tap Preview/Program mode
- Select between single-tap/double-tap in QUAD menu
Quad-HD Live-Switch: Expanded SDI Monitor Output Options
- SDI A Out selectable between Quad-Split view or Preview
- SDI B Out selectable between Quad-Split view or Program
SDI A Out options in Output menu:
- LUT OFF (Quad-Split view with no LUT applied)
- LUT ON (Quad-Split view with LUT applied)
- MIRROR OLED (Quad-Split view with Preview/Program and other overlays)
- LIVE-SWITCH PREVIEW (Preview input selection)
-
SDI B Out options in Output menu:
- LUT OFF (Quad-Split view with no LUT applied)
- LUT ON (Quad-Split view with LUT applied)
- MIRROR OLED (Quad-Split view with Preview/Program and other overlays)
- LIVE-SWITCH PROGRAM (Program input selection)
NOTE:
- When either output is set to Mirror OLED, LUT application mirrors OLED
- When SDI A Out is set to Live-Switch Preview, LUT is not applied
- When SDI B Out is set to Live-Switch Program, LUT application mirrors OLED
Quad-HD Quad-Split: Timecode Burn-In
- Timecode window is baked into the Quad-Split recorded image
NEW FEATURES: ODYSSEY RAW BUNDLE (ODYSSEY7Q+/7Q)
Odyssey RAW Bundle Grant
- Owners of individual RAW options granted full Odyssey RAW Bundle
- Log in at account on CD website for Activation code
- Odyssey7Q+/7Q Rental options are now Odyssey RAW Bundle and Apollo
Dual-HD Recording
- Record two HD video signals simultaneously in Apple ProRes (HQ/422/LT)
- Two SSDs required (one recording per SSD)
- Matching timecode (input A, input B, Odyssey-generated or LTC)
- Resolutions & frame rates must match
- No Genlock required
- 1080p 23.98, 24, 25, 29.97, 30
- 1080i 50, 60
- 720p 50, 60
Sony FS5 RAW Support
- Record RAW in CinemaDNG from the Sony PXW-FS5
- Record RAW -> Apple ProRes from the Sony PXW-FS5
- Note: Set FS5 to Picture Profile S-Log2, Color Mode S-Gamut/3200 or S-Gamut/5500
- 4K FS RAW -> 4K CinemaDNG 23.98, 25, 29.97, 50, 59.94
- 2K FS RAW -> 2K CinemaDNG 23.98, 25, 29.97, 50, 59.94, 100, 120, 200, 240
- 4K FS RAW Burst -> 4K CinemaDNG 100, 120
- 4K FS RAW -> 4K Apple ProRes 23.98, 25, 29.97, 50, 59.94
- 4K FS RAW -> UHD Apple ProRes 23.98, 25, 29.97, 50, 59.94
- 4K FS RAW -> 2K Apple ProRes 23.98, 25, 29.97, 50, 59.94
- 4K FS RAW -> HD Apple ProRes 23.98, 25, 29.97, 50, 59.94
- 2K FS RAW HS -> 2K Apple ProRes 100, 120, 200, 240
- 2K FS RAW HS -> HD Apple ProRes 100, 120, 200, 240
- 4K FS RAW Burst -> 4K/UHD Apple ProRes 100, 120
- 4K FS RAW Burst -> 2K/HD Apple ProRes 100, 120
IO 4K RAW support
- Record RAW in CinemaDNG from the IO Industries Flare 4K
- 4K RAW -> 4K CinemaDNG 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
NEW FEATURES: ALL MODELS (APOLLO, ODYSSEY7Q+/7Q/7)
8-Channel Audio Support
- Record 8-channel SDI embedded audio in Apple ProRes (HQ/422/LT)
- Up to 32 channels in Apollo Quad-HD (8 channels per video input)
- Up to 16 channels in Apollo Dual-4K (8 channels per video input)
- Up to 8 channels in Odyssey 4K/UHD/2K/HD
- SDI embedded only, HDMI & Analog In limited to 2-Channel audio
- Audio meters display first two channels per input (first four channels per input in Apollo Dual-4K)
- Audio Out & HDMI/SDI embedded out use first two channels of video input
- Note: 8-channel audio not available in RAW, RAW->Apple ProRes, DPX, or Apple ProRes 4444 modes
Focus Assist Noise Reduction
- Improves legibility of Focus Assist
- Does not affect recorded signal
- NOTE: Enhance mode removed
Embedded SDI Record Trigger Pass Through
- Passes through SDI record trigger signal from various cameras to SDI outputs
- Regardless of trigger source, output trigger is ARRI/Canon/Sony standard
In/Out Marker Range Limiting
- Use In/Out Markers to limit range of playback in unit
- Starting play from an In marker will automatically stop at Out Marker
- Select LOOP in Playlist to repeatedly play only the selected In/Out range
NEW FEATURES: ODYSSEY7
Overlays Output On/Off
- Switch on/off OLED overlays to HDMI & SDI outputs
- Select in Output menu
FIXES & IMPROVEMENTS
Apollo
- FIXED Rare file corruption issue
- FIXED 1080p60 signal detection issue
- FIXED Occasional audio delay on SDI & HDMI outputs
- IMPROVED SDI B output carries embedded audio
- IMPROVED Source Naming added to XML file
Odyssey RAW Bundle
- FIXED Rare Canon RAW -> Apple ProRes frame issue
- IMPROVED Sony FS RAW -> Apple ProRes 240p drive spanning enabled
- IMPROVED Sony FS7 4K FS RAW -> 4K/UHD Apple ProRes debayer color fringing issue (yellow artifact at sharp edges)
- IMPROVED Playback Scrubbing artifacts of RAW recordings
Odyssey7Q+/7Q
- FIXED DPX support for Sony F35
- IMPROVED DPX now supports 1080p60 over HDMI
- IMPROVED Playback of 4K Apple ProRes
- IMPROVED Playback scrubbing artifacts in 4K Apple ProRes
- IMPROVED Reduced display latency in single input HD Apple ProRes
All Devices
- FIXED Guides interaction with Hide function
- FIXED HDMI signal detection from computer sources
- FIXED Timecode issue with HDMI source in Time-of-Day mode
- IMPROVED Device boot-up time
- IMPROVED SDI/HDMI Record Trigger from Panasonic DVX200
- IMPROVED SDI/HDMI Record Trigger from Sony FS5/F5/F55
- IMPROVED Playback without an input connected
- IMPROVED Increased power draw efficiency
SOFTWARE
CD Apple ProRes Transfer Tool v2.4
- For Apollo multitrack recordings, added option to select tracks for offload
- Fixed Windows issues
- Windows and Mac versions available
CD LUT Converter 1.3
- To prevent formatting issues, in the Project and Notes fields these characters are no longer allowed: < > ‘ ” &
- Windows and Mac versions available
|
|
